Spur gear

A 24-tooth gear with a raised hub.

GearsHardwareParametric

A 24-tooth gear study with a raised hub and central bore. The editable source exposes tooth count, diameter, and thickness for quickly exploring proportions. The tooth profile is illustrative, not an engineering specification.

Download STL ↗

Free to use & adapt · CC BY 4.0

2Mesh parts

4.2kTriangles

3File formats

Model details

Dimensions (W × D × H)	85.1 × 85.1 × 23.8 mm
Model complexity	Intermediate
Mesh parts	2 separate meshes
Triangle count	4,224
Coordinate system	Millimetres · Y up
Created with	AI · Shared by Joshua
Added to the collection	29 August 2026
License	Creative Commons BY 4.0 ↗

A starting point for making. These are original concept models. Check dimensions, tolerances, mesh intersections, and material suitability before fabrication. Assembly exports contain multiple parts; separate and prepare them in your CAD or slicing tool.
